Variable voltage innovation

Features:

• Variable Voltage 12v AC ~ 32v AC
• Suits new and existing pools
• Quick Connect Plug Kit included
• Suits all Cable Thicknesses
• Includes Universal Mounting Bracket
• Australian Made

Aqua-Quip’s unique LED Variable Voltage technology has been incorporated into the QC Series Surface Mounted Pool Lights – for both new and existing concrete pool installations. The QC Series concept has evolved from a need for pool builders and technicians to most conveniently effect the wiring connection when installing either a new light in a new pool or retro-fitting in an existing pool, a task made simple with a choice of colour-coded cable seals of varying sizes ensuring an impervious fit on a wide range of cable thicknesses.

QC Series LED Lights for new concrete pools are provided with the Universal Mounting Bracket which is screwed or rendered to the pool wall. The Cable is supplied with a protective Cable Cap which allows the light only to be connected once the pool is ready to be filled. Although the lights are capable of operating at varying voltages, only use 12 Volt AC transformers for new pool construction to comply with Australian Standards (AS/NZS 3000:2007).

Energy Efficient

QC Series LEDs are energy efficient drawing only 15% of the power requirement of older style halogen lights. Thanks to the integrated heat sink QC Series LEDs also run well below their thermal rating significantly increasing their working life.

Variable Voltage Technology

Each QC Series Light is able to be operated from a supply voltage ranging from 12 Volt AC through to 32 Volt AC.

For retro-fitting – the existing transformer will not have to be replaced, saving money.

 Amazing LED Colours

Choose from fixed colours of white, blue or green for maximum illumination; or the Multi Colour option which incorporates the advanced Spectrum IX technology. The QC Series Multi Colour lights allow the user to select from a variety of pre-programmed scroll and flash modes as well as being able to choose from over 100 different “hold” colours.

New Style Back Plate

Newly designed back plate creates more space behind the light for extra cable to be secured. The raised flange on the back plate also provides for improved aesthetics.
